0:17:0 0106 01 1002 4391 1 11 C000 B000 A000 9000 8000

BIOS drive count: 5

BIOS Inter Bus Location Dev Port Intr
---- ----- --- -------- --- ---- ----
80 USB PCI 0:18:2 0
81 ATA PCI 0:20:1 M 14
82 ATA PCI 0:20:1 S 14
83 SATA PCI 0:17:0 M 11
84 SATA PCI 0:17:0 S 11

Command Control : Master : Slave

------- ------- : ------ : ------ -----Legacy controllers------
01F0 03F6 50 50 0101010000A050 0101010000B050
0170 0376 . . FFFFFFFFFFFFFF FFFFFFFFFFFFFF
01E8 03EE . . FFFFFFFFFFFFFF FFFFFFFFFFFFFF
0168 036E . . FFFFFFFFFFFFFF FFFFFFFFFFFFFF
-----PCI/ATA controllers-----
01F0 03F6 50 50 0101010000A050 0101010000B050
0170 0376 . . FFFFFFFFFFFFFF FFFFFFFFFFFFFF
C000 B002 50 50 0101010000A050 0101010000B050
A000 9002 . . FFFFFFFFFFFF7F 01010114EBB000

Cmnd Ctrl Sel Mast Intr Bios Clss If Location Drive Model
---- ---- --- ---- ---- ---- ---- -- -------- --------------------------
1. 01F0 03F6 0 FF00 14 81 0101 8A 0:20:1 WDC WD5000AAJB-00YRA0
2. 01F0 03F6 1 FF00 14 82 0101 8A 0:20:1 WDC WD5000AAJB-00YRA0
3. C000 B002 0 8000 11 83 0106 01 0:17:0 SAMSUNG HD154UI
4. C000 B002 1 8000 11 84 0106 01 0:17:0 SanDisk SDSSDHII240G

BIOS 87654321 62 63 65 66 88 Drive Model
---- -------- ---- ---- ---- ---- ---- ------------------------
1. 81 .####### 0000 0007 120 120 203F WDC WD5000AAJB-00YRA0
2. 82 .####### 0000 0007 120 120 203F WDC WD5000AAJB-00YRA0
3. 83 .#####.. 0000 0007 120 120 40FF SAMSUNG HD154UI
4. 84 .####... 0000 0007 120 120 407F SanDisk SDSSDHII240G

BIOS Size Drive Identity Location: 0 25% 50% 75% 100
---- ----- ---------------------------- ------- ------- ------- ------- -------
81 500GB WDC WD5000AAJB-00YRA0 79.1 75.8 69.8 61.1 38.9
82 500GB WDC WD5000AAJB-00YRA0 77.7 73.4 66.9 55.5 37.3
83 1TB SAMSUNG HD154UI 105.6 97.6 88.1 75.3 50.2
84 240GB SanDisk SDSSDHII240G 269.2 270.5 268.6 270.4 270.0

This clearly shows how much faster an SSD is than a rotating HDD. In fact the SSD on this ma-
chine is limited by the SATA II interface which only supports up to 300MBps. That SanDisk
should be capable of about 550MBps on a SATA III interface. NVMe disks on a PCIe interface
are even faster, the 1TB NVMe SSD on my new machine has benchmarked in excess of
1500MBps.
